Parts for repair only



Item Number:
SMOTOR-CV001M


Features:
12V, 1.4kW, 10TH , CW.
Multi Position Mounting


Suit:
Small & Big Block Fit For CHEV V8
All Gen 1 Family Motors
283 - 307 - 327 - 350 - 383 - 400 Small Block
396 - 427 - 454 - 502 - 572 Big Block
1.4kW Hi-Output 12V
Dual bolt pattern fits either 153 or 168 tooth flywheel / flexplates.
Allows starter to be used with automatic  manual transmissions.
Will not fit a staggered mount.


Specifications:
Volts    12V
Kilowatts    1.4kW
Teeth    10TH
Rotation    CW
Mount Hole Diameter    2 x 10mm
Flange Diameter    82mm
Pinion At Rest    10mm
Pinion Diameter    28mm
Overall Length    198mm
Mounting Hole Centres       83mm


Package:
1* Starter Motor



This starter comes with 10 teeth, the other type is teeth, please check yours before purchasing.

SKU SMOTOR-CV001M
Brand POWEROY
Shipping Weight 5.0000kg
Shipping Width 0.160m
Shipping Height 0.160m
Shipping Length 0.270m
Shipping Cubic 0.006912000m3
